In the transportation of the materials, the belt conveyor measures the conveyor’s loading capacity, the connection speed and the pulse output ratio of the velocity transducer through the balanced frame weight tape. After constant measurement, the device transfers the installing speed and the high speed signal of the velocity sensor to the feeder line weight controller which is the microprocessor to control the total production and instantaneous delivery. The traffic flow and the output signal control the belt conveyor to meet the measurement requirement.
| Belt Width (mm) |
Conveying length (m) Power (kw) |
Conveying speed (m/s) |
Conveying capacity (t/h) |
||
| 400 | ≤10 2.2 |
10-15 3-4 |
15-30 4-7.5 |
1.25-2.0 | 30-60 |
| 500 | ≤10 3 |
10-15 4-5.5 |
15-30 5.5-7.5 |
1.25-2.0 | 40-80 |
| 650 | ≤10 4 |
10-15 7.5 |
15-30 7.5-11 |
1.25-2.0 | 80-120 |
| 800 | ≤10 5.5 |
10-15 7.5 |
15-30 7.5-15 |
1.25-2.0 | 120-200 |
| 1000 | ≤10 7.5 |
10-20 7.5-11 |
20-40 11-22 |
1.25-2.0 | 200-320 |
| 1200 | ≤10 11 |
10-20 11-15 |
20-40 15-30 |
1.25-2.0 | 290-480 |
| 1400 | ≤10 15 |
10-20 15-22 |
20-40 22-45 |
1.25-2.0 | 400-680 |
| 1600 | ≤10 18.5 |
10-20 18.5-30 |
20-50 30-75 |
1.25-2.0 | 600-1080 |
| 1800 | ≤10 22 |
10-20 22-45 |
20-50 45-110 |
1.0-2.0 | 800-1500 |
| 2000 | ≤10 30 |
10-20 30-55 |
20-50 55-13 |
1.0-2.0 | 1000-2000 |
| 2400 | ≤10 45 |
10-20 45-75 |
20-50 75-185 |
1.0-2.0 | 1500-3000 |
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
| Belt Width (mm) |
Conveying speed (m/s) |
Conveying capacity (t/h) |
| 400 | 1.25-2.0 | 30-60 |
| 500 | 1.25-2.0 | 40-80 |
| 650 | 1.25-2.0 | 80-120 |
| 800 | 1.25-2.0 | 120-200 |
| 1000 | 1.25-2.0 | 200-320 |
| 1200 | 1.25-2.0 | 290-480 |
| 1400 | 1.25-2.0 | 400-680 |
| 1600 | 1.25-2.0 | 600-1080 |
| 1800 | 1.0-2.0 | 800-1500 |
| 2000 | 1.0-2.0 | 1000-2000 |
| 2400 | 1.0-2.0 | 1500-3000 |
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
Through long-term arduous technology research and international communication, our product quality has been in line with international level, winning a world-wide acclaim and honor, and our products are exported to ninety countries and regions like Tanzania, Nigeria, South Africa, Kenya, Turkey, Saudi Arabia, Philippines, Indonesia, Malaysia, Vietnam, Mexico, Brazil, Russia, Uzbekistan, Australia, etc.
