The rotation of the motor is driven by the eccentric bushing via the belt wheel, coupling, transmission shaft and the cone device to circle around the fixed shaft. The crushing wall of cone crushers goes near or away from the roll surface of the adjusting sleeve. Materials in the crushing cavity are impacted, compressed and warped constantly, thus realizing the crushing process.
When the cone crusher is working, the motor rotates through the pulley or coupling, the transmission shaft and the cone part to make a pendulum motion around a fixed part under the force of the eccentric sleeve, forcing the crushing wall to sometimes approach and sometimes deviate from the whitening wall surface fixed on the adjusting sleeve. In this way, the ore will be continuously impacted, squeezed and bent in the crushing chamber to achieve ore crushing.
Leave us a message for more details?
| Specification | Model | Diameter of large end of crushing cone (mm) |
Max.feeding size(mm) |
Width of discharge opening (mm) |
Processing capacity (t/h) |
Motor power (kw) |
Total weight （t） |
Dimensions (L×W×H) （mm） |
| Φ600 | PYB600 | 600 | 65 | 12-25 | 40 | 8P 30 | 5 | 2234×1370×1675 |
| PYD600 | 35 | 3-13 | 12-23 | 5.5 | 2234×1370×1675 | |||
| Φ900 | PYB900 | 900 | 115 | 15-50 | 50-90 | 8P 55 | 11.2 | 2692×1640×2350 |
| PYZ900 | 60 | 5-20 | 20-65 | 11.2 | 2692×1640×2350 | |||
| PYD900 | 50 | 3-13 | 15-50 | 11.3 | 2692×1640×2350 | |||
| Φ1200 | PYB1200 | 1200 | 145 | 20-50 | 110-168 | 8P 110 | 24.7 | 2790×1878×2844 |
| PYZ1200 | 100 | 8-25 | 42-135 | 25 | 2790×1878×2844 | |||
| PYD1200 | 50 | 3-15 | 18-105 | 25.3 | 2790×1878×2844 | |||
| Φ1750 | PYB1750 | 1750 | 215 | 25-50 | 180-360 | 8P 160 | 50.3 | 3910×2894×3809 |
| PYZ1750 | 185 | 10-30 | 80-210 | 50.3 | 3910×2894×3809 | |||
| PYD1750 | 85 | 5-13 | 60-180 | 50.2 | 3910×2894×3809 | |||
| Φ2200 | PYB2200 | 2200 | 300 | 30-60 | 420-700 | 8P 280-260 | 80 | 4622×3302×4470 |
| PYZ2200 | 230 | 10-30 | 130-410 | 80 | 4622×3302×4470 | |||
| PYD2200 | 100 | 5-15 | 80-200 | 81.4 | 4622×3302×4470 |
| Specification | Model | Diameter of large end of crushing cone (mm) |
Processing capacity (t/h) |
| Φ600 | PYB600 | 600 | 40 |
| PYD600 | 12-23 | ||
| Φ900 | PYB900 | 900 | 50-90 |
| PYZ900 | 20-65 | ||
| PYD900 | 15-50 | ||
| Φ1200 | PYB1200 | 1200 | 110-168 |
| PYZ1200 | 42-135 | ||
| PYD1200 | 18-105 | ||
| Φ1750 | PYB1750 | 1750 | 180-360 |
| PYZ1750 | 80-210 | ||
| PYD1750 | 60-180 | ||
| Φ2200 | PYB2200 | 2200 | 420-700 |
| PYZ2200 | 130-410 | ||
| PYD2200 | 80-200 |
Through long-term arduous technology research and international communication, our product quality has been in line with international level, winning a world-wide acclaim and honor, and our products are exported to ninety countries and regions like Tanzania, Nigeria, South Africa, Kenya, Turkey, Saudi Arabia, Philippines, Indonesia, Malaysia, Vietnam, Mexico, Brazil, Russia, Uzbekistan, Australia, etc.
